Samtec BCS-104-L-S-TE
артикул BCS-104-L-S-TE
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8536.69.40.40
Automotive
No
PPAP
No
Type
Socket Strip
Gender
SKT
Number of Contacts
4
Number of Rows
1
Termination Method
Solder
Terminal Pitch (mm)
2.54
Body Orientation
Straight
Maximum Current Rating (A)
4.6/Contact
Maximum Voltage Rating
475VAC
Maximum Contact Resistance (mOhm)
10
Minimum Operating Temperature (В°C)
-55
Maximum Operating Temperature (В°C)
125
Mating Cycle (Cycles)
2500
Packaging
Layer
Product Length (mm)
10.16
Product Depth (mm)
2.54
Product Height (mm)
7.37
Tradename
TIGER CLAWв„ў
Tail Length (mm)
3.1
Mounting
Through Hole
Показать все
Описание
Protect your printed circuit boards from accidental damages with Samtec&s;s socket strip BCS-104-L-S-TE header connector. This SKT connector&s;s 4 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. This is a 1-row connector. It has a maximum voltage rating of 475 VAC. It has a socket type gender. It has a straight body orientation. This device has a maximum current rating of 4.6 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. BCS-104-L-S-TE is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 В°C. This product is 10.16 mm long, 7.37 mm tall and 2.54 mm deep.
Похожие товары
Samtec
Conn Socket Strip SKT 4 POS 2.54mm Solder ST Top Entry Thru-Hole Tube
Samtec
Conn Socket Strip SKT 4 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk
Samtec
Conn Socket Strip SKT 4 POS 2.54mm Solder ST Top Entry Thru-Hole Tiger Buyв„ў Tube
TE Connectivity
Conn Socket Strip SKT 4 POS 2.54mm Solder ST Top Entry Thru-Hole Box/Tube
