Texas Instruments LMC6041IN/NOPB
артикул LMC6041IN/NOPB
Texas Instruments
производитель
Op Amp Single Micropower Amplifier R-R O/P 15.5V 8-Pin PDIP Tube
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.33.00.01
Automotive
No
PPAP
No
Type
Micropower Amplifier
Manufacturer Type
Micropower Amplifier
Number of Channels per Chip
1
Rail to Rail
Rail to Rail Output
Process Technology
CMOS
Output Type
CMOS
Maximum Input Offset Voltage (mV)
6@5V
Minimum Single Supply Voltage (V)
4.5
Typical Single Supply Voltage (V)
5; 9; 12; 15
Maximum Single Supply Voltage (V)
15.5
Maximum Input Offset Current (uA)
0.000000001(Typ)@5V
Typical Input Bias Current (uA)
0.000000002@5V
Maximum Input Bias Current (uA)
0.000004@5V@-40C to 85C
Maximum Supply Current (mA)
0.026@5V
Typical Output Current (mA)
22@5V
Power Supply Type
Single
Typical Slew Rate (V/us)
0.02@5V
Typical Input Noise Voltage Density (nV/rtHz)
83@5V
Typical Voltage Gain (dB)
120
Typical Noninverting Input Current Noise Density (pA/rtHz)
0.0002@5V
Minimum PSRR (dB)
62
Minimum CMRR (dB)
62
Minimum CMRR Range (dB)
60 to 65
Typical Gain Bandwidth Product (MHz)
0.075
Shut Down Support
No
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Supplier Temperature Grade
Industrial
Packaging
Tube
Supplier Package
PDIP
Pin Count
8
Standard Package Name
DIP
Mounting
Through Hole
Package Height
5.08(Max) - 0.51(Min)
Package Length
10.16(Max)
Package Width
6.6(Max)
PCB changed
8
Lead Shape
Through Hole
Показать все
Описание
Single, 15.5-V, 75-kHz operational amplifier 8-PDIP -40 to 85
Op Amp Single Micropower Amplifier R-R O/P 15.5V 8-Pin PDIP Tube
Operational Amplifier, 1 Func, 6000uV Offset-Max, CMOS, PDIP8
IC, OP AMP, SINGLE, 75KHZ; Op Amp Type:Low Power; No. of Amplifiers:1; Bandwidth:75kHz; Slew Rate:0.02V/µs; Supply Voltage Range:4.5V to 15.5V; Amplifier Case Style:DIP; No. of Pins:8; Operating Temperature Range:-40°C to +85°C; SVHC:No SVHC (19-Dec-2011); Gain Bandwidth:75kHz; I/O Type:Rail-Rail Outputs; Input Offset Voltage Max:6.3mV; Package / Case:DIP; Slew Rate:0.02V/µs; Supply Voltage Max:16V; Supply Voltage Min:4.5V; Termination Type:Through Hole
