STMicroelectronics LMC6482IDT
артикул LMC6482IDT
STMicroelectronics
производитель
Op Amp Dual GP R-R I/O 16V 8-Pin SO N T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.33.00.01
Automotive
No
PPAP
No
Type
General Purpose Amplifier
Manufacturer Type
General Purpose Amplifier
Number of Channels per Chip
2
Rail to Rail
Rail to Rail Input/Output
Process Technology
CMOS
Output Type
CMOS
Maximum Input Offset Voltage (mV)
2@16V
Minimum Single Supply Voltage (V)
2.7
Typical Single Supply Voltage (V)
3; 5; 9; 12; 15
Maximum Single Supply Voltage (V)
16
Maximum Input Offset Current (uA)
0.00005@16V
Typical Input Bias Current (uA)
0.000001@16V
Maximum Input Bias Current (uA)
0.00005@16V
Maximum Quiescent Current (mA)
1.8@16V
Typical Output Current (mA)
68@16V
Power Supply Type
Single
Typical Slew Rate (V/us)
1.4@16V
Typical Input Noise Voltage Density (nV/rtHz)
22@16V
Typical Voltage Gain (dB)
149
Minimum CMRR (dB)
75
Minimum CMRR Range (dB)
75 to 80
Typical Gain Bandwidth Product (MHz)
2.7
Shut Down Support
No
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Supplier Temperature Grade
Extended
Packaging
Tape and Reel
Supplier Package
SO N
Pin Count
8
Mounting
Surface Mount
Package Height
1.65(Max)
Package Length
5(Max)
Package Width
4(Max)
PCB changed
8
Показать все
Описание
LMC6482 Series 16 V 2.7 MHz Dual Rail-to-Rail Operational Amplifier - SOIC-8
Rail-to-rail 16V CMOS operational amplifier, dual, GBP 2.7MHz, -40 to 125°C, SO-8, Tape and Reel
Operational Amplifier, 1 Func, 2500uV Offset-Max, CMOS, PDSO8
Operational Amplifiers - Op Amps 16 V CMOS dual rail-to-rail input and output, operational amplifier
OP Amp Dual 1.4V/us 2.7V to 16V 8-Pin SOIC T/R
