Texas Instruments SN74HC273PWR
артикул SN74HC273PWR
Texas Instruments
производитель
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin TSSOP T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
SVHC
Yes
Automotive
No
PPAP
No
Logic Family
HC
Logic Function
D-Type Bus Interface
Number of Channels per Chip
8
Number of Elements per Chip
1
Number of Element Inputs
8
Number of Element Outputs
8
Bus Hold
No
Set/Reset
Master Reset
Polarity
Non-Inverting
Triggering Type
Positive-Edge
Maximum Propagation Delay Time @ Maximum CL (ns)
160@2V; 32@4.5V; 27@6V
Absolute Propagation Delay Time (ns)
200
Process Technology
CMOS
Input Signal Type
Single-Ended
Maximum Low Level Output Current (mA)
5.2
Maximum High Level Output Current (mA)
-5.2
Minimum Operating Supply Voltage (V)
2
Typical Operating Supply Voltage (V)
5
Maximum Operating Supply Voltage (V)
6
Maximum Quiescent Current (mA)
0.008
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Supplier Temperature Grade
Commercial
Packaging
Tape and Reel
Standard Package Name
SOP
Pin Count
20
Supplier Package
TSSOP
Mounting
Surface Mount
Package Height
1.05(Max)
Package Length
6.6(Max)
Package Width
4.5(Max)
PCB changed
20
Lead Shape
Gull-wing
Показать все
Описание
Are you looking to store information at a basic level? The SN74HC273PWR flip flop device from Texas Instruments can easily save state information. It has a single-ended output signal. This flip flop has a minimum operating temperature of -40 В°C and a maximum of 85 В°C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
