Texas Instruments SN74HCT273DWR
артикул SN74HCT273DWR
Texas Instruments
производитель
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin SOIC T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Logic Family
HCT
Logic Function
D-Type Bus Interface
Number of Channels per Chip
8
Number of Elements per Chip
1
Number of Element Inputs
8
Number of Element Outputs
8
Bus Hold
No
Set/Reset
Master Reset
Polarity
Non-Inverting
Triggering Type
Positive-Edge
Absolute Propagation Delay Time (ns)
42
Process Technology
CMOS
Input Signal Type
Single-Ended
Maximum Low Level Output Current (mA)
4
Maximum High Level Output Current (mA)
-4
Minimum Operating Supply Voltage (V)
4.5
Typical Operating Supply Voltage (V)
5
Maximum Operating Supply Voltage (V)
5.5
Maximum Quiescent Current (mA)
0.008
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Supplier Temperature Grade
Commercial
Packaging
Tape and Reel
Standard Package Name
SOP
Pin Count
20
Supplier Package
SOIC
Mounting
Surface Mount
Package Height
2.35(Max)
Package Length
13(Max)
Package Width
7.6(Max)
PCB changed
20
Lead Shape
Gull-wing
Показать все
Описание
Thanks to Texas Instruments and their SN74HCT273DWR flip flop device, you can ensure that your state information is saved and available for later use. It has a single-ended output signal. This flip flop has an operating temperature range of -40 В°C to 85 В°C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
