Texas Instruments SN74LVC1G04DBVR
артикул SN74LVC1G04DBVR
Texas Instruments
производитель
Inverter 1-Element CMOS 5-Pin SOT-23 T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Logic Family
LVC
Logic Function
Inverter
Number of Elements per Chip
1
Maximum Propagation Delay Time @ Maximum CL (ns)
4.2@3.3V; 3.7@5V
Absolute Propagation Delay Time (ns)
7.5
Process Technology
CMOS
Output Type
Push-Pull
Maximum Low Level Output Current (mA)
32
Maximum High Level Output Current (mA)
-32
Minimum High Level Output Voltage (V)
1.2
Maximum Low Level Output Voltage (V)
0.55
Minimum Operating Supply Voltage (V)
1.65
Typical Operating Supply Voltage (V)
1.8; 2.5; 3.3; 5
Maximum Operating Supply Voltage (V)
5.5
Maximum Quiescent Current (uA)
10
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Pin Count
5
Supplier Package
SOT-23
Standard Package Name
SOT
Mounting
Surface Mount
Package Height
1.1
Package Length
3.05(Max)
Package Width
1.75(Max)
PCB changed
5
Lead Shape
Gull-wing
Показать все
Описание
The SN74LVC1G04DBVR inverting Schmitt trigger, developed by Texas Instruments, is a great device for removing noise from an analog signal. This inverting Schmitt trigger has a minimum operating temperature of -40 В°C and a maximum of 125 В°C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 5.5 V.
