Texas Instruments SN65LVDS2DBVTG4
артикул SN65LVDS2DBVTG4
Texas Instruments
производитель
LVDS Receiver 400Mbps 0.454V 5-Pin SOT-23 T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Function
Receiver
Number of Drivers
0
Number of Receivers
1
Number of Elements per Chip
1
Transmission Data Rate (Mbps)
400
Maximum Propagation Delay Time (ns)
3.1
Maximum Operating Frequency (MHz)
200
Input Signal Type
LVDS
Minimum Operating Supply Voltage (V)
2.4
Maximum Operating Supply Voltage (V)
3.6
Differential Input Low Threshold Voltage (V)
-0.1(Min)
Differential Input High Threshold Voltage (V)
0.1(Max)
Maximum Differential Output Voltage (V)
0.454
Typical Operating Supply Voltage (V)
3.3
Maximum Input Current (uA)
20
Maximum Power Dissipation (mW)
60(Typ)
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Pin Count
5
Standard Package Name
SOT-23
Supplier Package
SOT-23
Mounting
Surface Mount
Package Height
1.1
Package Length
3.05(Max)
Package Width
1.75(Max)
PCB changed
5
Lead Shape
Gull-wing
Показать все
Описание
400-Mbps LVDS single high-speed receiver 5-SOT-23 -40 to 85
DIFFERENTIAL LINE DRIVER/RECEIVER SIGNAL SOT23-5, FULL REEL
LVDS Driver/Receiver 400Mbps 0.454V 5-Pin SOT-23 T/R
Line Receiver, 1 Func, 1 Driver, 1 Rcvr, TTL, PDSO5
IC DIFF LINE DVR/RCVR HS SOT23-5
LVDS/M-LVDS/ECL/CML SINGLE LVDS RECEIVER
HIGH SPEED DIFFERENTIAL RECEIVER
