Texas Instruments SN65LVDM180PWR
артикул SN65LVDM180PWR
Texas Instruments
производитель
LVDS Driver/Receiver 100Mbps 0.454V 14-Pin TSSOP T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
5A991b.1.
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Function
Driver/Receiver
Number of Drivers
1
Number of Receivers
1
Number of Elements per Chip
1
Transmission Data Rate (Mbps)
100
Maximum Propagation Delay Time (ns)
4.5
Maximum Operating Frequency (MHz)
200
Input Signal Type
LVTTL
Minimum Operating Supply Voltage (V)
3
Maximum Operating Supply Voltage (V)
3.6
Differential Input Low Threshold Voltage (V)
-0.05
Differential Input High Threshold Voltage (V)
0.05
Maximum Differential Output Voltage (V)
0.454
Typical Operating Supply Voltage (V)
3.3
Maximum Input Current (uA)
20
Maximum Power Dissipation (mW)
736
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Packaging
Tape and Reel
Pin Count
14
Standard Package Name
SOP
Supplier Package
TSSOP
Mounting
Surface Mount
Package Height
1.05(Max)
Package Length
5.1(Max)
Package Width
4.5(Max)
PCB changed
14
Lead Shape
Gull-wing
Показать все
Описание
Full-duplex LVDM transceiver with driver and receiver enable 14-TSSOP -40 to 85
HIGH-SPEED DIFFERENTIAL LINE DRIVERS AND RECEIVERS | IC DIFF LINE DVR/RCVR HS 14TSSOP
LVDS Driver/Receiver 100Mbps 0.454V 14-Pin TSSOP T/R
Line Transceiver, 1 Func, 1 Driver, 1 Rcvr, CMOS, PDSO14
LVDS/M-LVDS/ECL/CML Full-Duplex LVDM Transceiver
IC TRANSCEIVER FULL 1/1 14TSSOP
Product Description Demo for Development.
IC,TEXASINST,SN65LVDM180PWR
