Texas Instruments SN65LVDS1DBVTG4
артикул SN65LVDS1DBVTG4
Texas Instruments
производитель
LVDS Driver 630Mbps 0.454V 5-Pin SOT-23 T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Function
Driver
Number of Drivers
0
Number of Receivers
1
Number of Elements per Chip
1
Transmission Data Rate (Mbps)
630
Maximum Propagation Delay Time (ns)
3.1
Maximum Operating Frequency (MHz)
200
Input Signal Type
LVDS
Minimum Operating Supply Voltage (V)
2.4
Maximum Operating Supply Voltage (V)
3.6
Differential Input Low Threshold Voltage (V)
-0.1(Min)
Differential Input High Threshold Voltage (V)
0.1(Max)
Maximum Differential Output Voltage (V)
0.454
Typical Operating Supply Voltage (V)
3.3
Maximum Input Current (uA)
20
Maximum Power Dissipation (mW)
25(Typ)
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Packaging
Tape and Reel
Pin Count
5
Standard Package Name
SOT
Supplier Package
SOT-23
Mounting
Surface Mount
Package Height
1.1
Package Length
3.05(Max)
Package Width
1.75(Max)
PCB changed
5
Lead Shape
Gull-wing
Показать все
Описание
630-Mbps single LVDS driver 5-SOT-23 -40 to 85
DIFFERENTIAL LINE DRIVER/RECEIVER SIGNAL SOT23-5, FULL REEL
LVDS Driver/Receiver 630Mbps 0.454V 5-Pin SOT-23 T/R
Line Driver, 1 Func, 1 Driver, 1 Rcvr, TTL, PDSO5
LVDS/M-LVDS/ECL/CML Single LVDS Transmitter
IC DIFF LINE DVR/RCVR HS SOT23-5
IC AUDIO CODEC 24B I2C 64HTQFP
HIGH SPEED DIFFERENTIAL DRIVER
