Texas Instruments CD74HC4053M96
артикул CD74HC4053M96
Texas Instruments
производитель
Analog Multiplexer Triple 2:1 16-Pin SOIC T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
SVHC
Yes
Automotive
No
PPAP
No
Type
Analog Multiplexer
Configuration
Triple 2:1
Multiplexer Architecture
2:1
Number of Channels per Chip
3
Number of Inputs per Chip
6
Number of Outputs per Chip
3
Chip Enable Signals
Yes
Maximum Propagation Delay Bus to Bus (ns)
8@В±4.5V; 10@6V; 12@4.5V; 60@2V
Maximum Turn-On Time (ns)
220@2V
Maximum Turn-Off Time (ns)
210@2V
Maximum Frequency (25В°C) @ Vcc (MHz)
200(Typ)@В±4.5V
Input Signal Type
Single
Output Signal Type
Single
Minimum Single Supply Voltage (V)
2
Typical Single Supply Voltage (V)
3; 5
Maximum Single Supply Voltage (V)
6
Minimum Dual Supply Voltage (V)
0; 2
Typical Dual Supply Voltage (V)
В±3; В±5
Maximum Dual Supply Voltage (V)
В±6
Maximum Low Level Output Current (mA)
25
Maximum High Level Output Current (mA)
25
Maximum On Resistance (Ohm)
180@4.5V
Maximum On Resistance Range (Ohm)
150 to 250
Propagation Delay Test Condition (pF)
50
Power Supply Type
Single; Dual
Minimum Operating Temperature (В°C)
-55
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Pin Count
16
Standard Package Name
SOP
Supplier Package
SOIC
Mounting
Surface Mount
Package Height
1.5(Max)
Package Length
10(Max)
Package Width
4(Max)
PCB changed
16
Lead Shape
Gull-wing
Показать все
Описание
5-V, 2:1 (SPDT) 3-channel analog switch 16-SOIC -55 to 125
ANALOGUE MUX/DEMUX, TRIPLE, 2: 1, SOIC-16; Configuration multiplexeur: 2: 1; Nombre de circuits: 3Circuit(s); Résistance, Ron, max..: 0.13ohm; Gamme de tension d'alimentation: 2V à 6V; Boîtier multiplexeur analogique: SOIC; Nom
Analogue Mux/Demux, Triple, 2:1, Soic-16; Multiplexer Configuration:2:1; No. Of Circuits:3Circuits; On State Resistance Max:0.13Ohm; Supply Voltage Range:2V To 6V; Analogue Multiplexer Case:Soic; No. Of Pins:16Pins; Operating Rohs Compliant: Yes |Texas Instruments CD74HC4053M96
