Texas Instruments SN74AC74N
артикул SN74AC74N
Texas Instruments
производитель
Flip Flop D-Type Pos-Edge 2-Element 14-Pin PDIP Tube
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Logic Family
AC
Logic Function
D-Type
Number of Channels per Chip
2
Number of Elements per Chip
2
Number of Element Inputs
1
Number of Element Outputs
1
Bus Hold
No
Set/Reset
Set/Reset
Polarity
Inverting/Non-Inverting
Triggering Type
Positive-Edge
Maximum Propagation Delay Time @ Maximum CL (ns)
10@5V; 14@3.3V
Absolute Propagation Delay Time (ns)
16
Process Technology
CMOS
Input Signal Type
Single-Ended
Maximum Low Level Output Current (mA)
24
Maximum High Level Output Current (mA)
-24
Minimum Operating Supply Voltage (V)
2
Typical Operating Supply Voltage (V)
3.3; 5; 2.5
Maximum Operating Supply Voltage (V)
6
Maximum Quiescent Current (mA)
0.002
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Supplier Temperature Grade
Commercial
Packaging
Tube
Standard Package Name
DIP
Supplier Package
PDIP
Pin Count
14
Mounting
Through Hole
Package Height
5.08(Max) - 0.51(Min)
Package Length
19.69(Max)
Package Width
6.6(Max)
PCB changed
14
Lead Shape
Through Hole
Показать все
Описание
The SN74AC74N flip flop device from Texas Instruments is designed specifically to save basic state information within your circuit. It has a differential output signal. This flip flop has an operating temperature range of -40 В°C to 85 В°C. This device comes in tube packaging. This inverting/non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V. It has 2 channels per chip.
