Texas Instruments SN74AHC273PWR
артикул SN74AHC273PWR
Texas Instruments
производитель
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin TSSOP T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
SVHC
Yes
Automotive
No
PPAP
No
Logic Family
AHC
Logic Function
D-Type Bus Interface
Number of Channels per Chip
8
Number of Elements per Chip
1
Number of Element Inputs
8
Number of Element Outputs
8
Bus Hold
No
Set/Reset
Master Reset
Polarity
Non-Inverting
Triggering Type
Positive-Edge
Maximum Propagation Delay Time @ Maximum CL (ns)
11@5V; 17.1@3.3V
Absolute Propagation Delay Time (ns)
19.5
Process Technology
CMOS
Input Signal Type
Single-Ended
Maximum Low Level Output Current (mA)
8
Maximum High Level Output Current (mA)
-8
Minimum Operating Supply Voltage (V)
2
Typical Operating Supply Voltage (V)
5; 3.3; 2.5
Maximum Operating Supply Voltage (V)
5.5
Maximum Quiescent Current (mA)
0.004
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Standard Package Name
SOP
Pin Count
20
Supplier Package
TSSOP
Mounting
Surface Mount
Package Height
1.05(Max)
Package Length
6.6(Max)
Package Width
4.5(Max)
PCB changed
20
Lead Shape
Gull-wing
Показать все
Описание
Store state information by enabling this SN74AHC273PWR flip flop device from Texas Instruments. It has a single-ended output signal. This flip flop has an operating temperature range of -40 В°C to 125 В°C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V.
