Nexperia 74AHCT273D,118
артикул 74AHCT273D,118
Nexperia
производитель
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin SO T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Logic Family
AHCT
Logic Function
D-Type Bus Interface
Number of Channels per Chip
8
Number of Elements per Chip
1
Number of Element Inputs
8
Number of Element Outputs
8
Bus Hold
No
Set/Reset
Master Reset
Polarity
Non-Inverting
Triggering Type
Positive-Edge
Maximum Propagation Delay Time @ Maximum CL (ns)
9.2@4.5V to 5.5V
Absolute Propagation Delay Time (ns)
14
Process Technology
CMOS
Input Signal Type
Single-Ended
Maximum Low Level Output Current (mA)
8
Maximum High Level Output Current (mA)
-8
Minimum Operating Supply Voltage (V)
4.5
Typical Operating Supply Voltage (V)
5
Maximum Operating Supply Voltage (V)
5.5
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Supplier Package
SO
Pin Count
20
Mounting
Surface Mount
Package Height
2.45(Max)
Package Length
13(Max)
Package Width
7.6(Max)
PCB changed
20
Показать все
Описание
74AHC273; 74AHCT273 - Octal D-type flip-flop with reset; positive-edge trigger
74AHCT Series 5.5 V Octal D-Type Flip-Flop with Reset - SOIC-20
Tape & Reel (TR) 74AHCT273 e4 74AHCT flip flop 2.65mm 9.2ns @ 5V 50pF 75MHz 4ns
FLIP-FLOP, D-TYPE, 75MHZ, SOIC-20; Logic Family / Base Number: 74AHCT273; Flip-Flop Type: D; Propagation Delay: -; Frequency: 75MHz; Output Current: 25mA; Logic Case Style: SOIC; No. of Pins: 20Pins; Trigger Type: Positive Edge;
