Nexperia 74AHC373PW,118
артикул 74AHC373PW,118
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Type
D-Type
Logic Family
AHC
Latch Mode
Transparent
Number of Channels per Chip
8
Number of Elements per Chip
1
Number of Inputs per Chip
8
Number of Input Enables per Element
1
Number of Selection Inputs per Element
0
Number of Outputs per Chip
8
Number of Output Enables per Element
1
Bus Hold
No
Set/Reset
No
Polarity
Non-Inverting
Maximum Propagation Delay Time @ Maximum CL (ns)
14.9@3V to 3.6V; 9.2@4.5V to 5.5V
Absolute Propagation Delay Time (ns)
19
Process Technology
CMOS
Output Type
3-State
Maximum Low Level Output Current (mA)
8
Maximum High Level Output Current (mA)
-8
Minimum Operating Supply Voltage (V)
2
Typical Operating Supply Voltage (V)
5
Maximum Operating Supply Voltage (V)
5.5
Maximum Quiescent Current (uA)
4
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Supplier Package
TSSOP
Pin Count
20
Mounting
Surface Mount
Package Height
0.95(Max)
Package Length
6.6(Max)
Package Width
4.5(Max)
PCB changed
20
Показать все
Описание
74AHC Series 5V 3-State Octal D-Type Transparant Latch Surface Mount - TSSOP-20
74AHC373 Tape & Reel (TR) AHC 74AHC latch circuit 8mA 8mA 19ns 6.5mm -40C~125C
LATCH, D TYPE TRANSP, 3-STATE, TSSOP-20; Logic Family / Base Number: 74AHC373; Latch Type: D Type Transparent; IC Output Type: Tri State Inverted; Propagation Delay: -; Output Current: 25mA; Logic Case Style: TSSOP; No. of Pins: 20Pins; Supply Voltage Min: 2V; Supply Voltage Max: 5.5V; No. of Bits: 8bit; Logic IC Family: 74AHC; Logic IC Base Number: 74373; Operating Temperature Min: -40°C; Operating Temperature Max: 125°C; Product Range: -; Automotive Qualification Standard: -; RoHS Phthalates Compliant: Yes; MSL: MSL 1 - Unlimited; SVHC: No SVHC (27-Jun-2018)
