Texas Instruments SN74AC04N
артикул SN74AC04N
Texas Instruments
производитель
Inverter 6-Element CMOS 14-Pin PDIP Tube
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Logic Family
AC
Logic Function
Inverter
Number of Elements per Chip
6
Maximum Propagation Delay Time @ Maximum CL (ns)
9@3.3V; 7@5V
Absolute Propagation Delay Time (ns)
10
Process Technology
CMOS
Output Type
Push-Pull
Maximum Low Level Output Current (mA)
24
Maximum High Level Output Current (mA)
-24
Minimum Operating Supply Voltage (V)
2
Typical Operating Supply Voltage (V)
2.5; 3.3; 5
Maximum Operating Supply Voltage (V)
6
Maximum Quiescent Current (uA)
2
Propagation Delay Test Condition (pF)
50
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Packaging
Tube
Supplier Package
PDIP
Pin Count
14
Standard Package Name
DIP
Mounting
Through Hole
Package Height
5.08(Max) - 0.51(Min)
Package Length
19.69(Max)
Package Width
6.6(Max)
PCB changed
14
Lead Shape
Through Hole
Показать все
Описание
Texas Instruments brings you their latest SN74AC04N inverting Schmitt trigger, from which you can convert an analog signal into a digital signal. This inverting Schmitt trigger has a minimum operating temperature of -40 В°C and a maximum of 85 В°C. This device comes in tube packaging. This device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
