Texas Instruments TL431ILPR
артикул TL431ILPR
Texas Instruments
производитель
V-Ref Adjustable 2.495V to 36V 100mA Automotive 3-Pin TO-92 T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Reference Type
Adjustable
Topology
Shunt
Initial Accuracy
2%
Maximum Temperature Coefficient
92ppm/В°C
Output Voltage (V)
2.495 to 36
Maximum Input Voltage (V)
37
Maximum Output Current (mA)
100
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Packaging
Tape and Reel
Supplier Package
TO-92
Pin Count
3
Standard Package Name
TO-92
Mounting
Through Hole
Package Height
5.34(Max)
Package Length
5.21(Max)
Package Width
4.19(Max)
PCB changed
3
Lead Shape
Formed
Показать все
Описание
Even in the event of large power supply variations, this TL431ILPR voltage reference power management device from Texas Instruments can produce and maintain a precise DC voltage. By working with a maximum input voltage of 37 V, this is the best way to control the power in your circuit. With an output that has a voltage of 2.495 to 36 V, this is power management at its best. It has an initial accuracy of 2%. This voltage reference circuit supports shunt topology. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This voltage reference circuit has an operating temperature range of -40 В°C to 85 В°C. It runs with a maximum temperature coefficient of 34ppm/В°C(Typ).
