ГлавнаяКаталогDrivers and InterfacesInterfaceLVDSTexas Instruments DS90LV032ATM/NOPB

Texas Instruments DS90LV032ATM/NOPB

артикул DS90LV032ATM/NOPB

Texas Instruments

производитель

LVDS Receiver 400Mbps 16-Pin SOIC Tube

По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.

Отправить запрос

Технические параметры

EU RoHS

Compliant

ECCN (US)

EAR99

Part Status

Active

HTS

8542.39.00.01

Automotive

PPAP

Function

Receiver

Number of Drivers

Number of Receivers

Number of Elements per Chip

Transmission Data Rate (Mbps)

400

Maximum Propagation Delay Time (ns)

3.3

Minimum Operating Frequency (MHz)

200

Maximum Operating Frequency (MHz)

250(Typ)

Input Signal Type

LVDS

Minimum Operating Supply Voltage (V)

Maximum Operating Supply Voltage (V)

3.6

Differential Input Low Threshold Voltage (V)

-0.1(Min)

Differential Input High Threshold Voltage (V)

0.1(Max)

Typical Operating Supply Voltage (V)

3.3

Maximum Input Current (uA)

Maximum Power Dissipation (mW)

1025

Minimum Operating Temperature (В°C)

-40

Maximum Operating Temperature (В°C)

Supplier Temperature Grade

Industrial

Packaging

Tube

Pin Count

Standard Package Name

SOP

Supplier Package

SOIC

Mounting

Surface Mount

Package Height

1.5(Max)

Package Length

10(Max)

Package Width

4(Max)

PCB changed

Lead Shape

Gull-wing

Показать все

Описание

3-V 400-Mbps LVDS quad differential line receiver 16-SOIC -40 to 85

Receiver IC; Supply Voltage Min:3V; Supply Voltage Max:3.6V; Termination Type:SMD; Package/Case:16-NSOIC; No. of Pins:16; Leaded Process Compatible:Yes; No. of Driver/Receivers:0/4; Peak Reflow Compatible (260 C):Yes ;RoHS Compliant: Yes

IC, LINE RECEIVER, QUAD, CMOS, DIFF; Device Type:Differential Receiver; Interface Type:LVDS; Propagation Delay:3.3ns; Supply Voltage Range:3V to 3.6V; Driver Case Style:SOP; No. of Pins:16; Operating Temperature Range:-40°C to +85°C; SVHC:No SVHC (20-Jun-2011); Data Rate:400Mbps; Interface Type:LVDS; No. of Receivers:4; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Output Current Max:120mA; Package / Case:SOP; Supply Current:10mA; Supply Voltage Max:3.6V; Supply Voltage Min:3V; Termination Type:SMD

Кроссы
