Texas Instruments LMV321M5/NOPB
артикул LMV321M5/NOPB
Texas Instruments
производитель
Op Amp Single Low Voltage Amplifier R-R O/P 5.5V 5-Pin SOT-23 T/R
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.33.00.01
Automotive
No
PPAP
No
Type
Low Voltage Amplifier
Manufacturer Type
Low Voltage Amplifier
Number of Channels per Chip
1
Rail to Rail
Rail to Rail Output
Process Technology
BiCMOS
Output Type
CMOS
Maximum Input Offset Voltage (mV)
7@5V
Minimum Single Supply Voltage (V)
2.7
Typical Single Supply Voltage (V)
3; 5
Maximum Single Supply Voltage (V)
5.5
Maximum Input Offset Current (uA)
0.05@5V
Typical Input Bias Current (uA)
0.015@5V
Maximum Input Bias Current (uA)
0.25@5V
Maximum Supply Current (mA)
0.44@5V
Typical Output Current (mA)
60
Power Supply Type
Single
Typical Slew Rate (V/us)
1@5V
Typical Input Noise Voltage Density (nV/rtHz)
39@5V
Input Offset Voltage Drift (uV/В°C)
5(Typ)
Typical Voltage Gain (dB)
100
Typical Noninverting Input Current Noise Density (pA/rtHz)
0.21@5V
Minimum PSRR (dB)
50
Minimum CMRR (dB)
50
Minimum CMRR Range (dB)
50 to 60
Typical Gain Bandwidth Product (MHz)
1
Shut Down Support
No
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Supplier Temperature Grade
Industrial
Packaging
Tape and Reel
Pin Count
5
Standard Package Name
SOT
Supplier Package
SOT-23
Mounting
Surface Mount
Package Height
1.1
Package Length
3.05(Max)
Package Width
1.75(Max)
PCB changed
5
Lead Shape
Gull-wing
Показать все
Описание
Op Amp Single Low Voltage Amplifier R-R O/P 5.5V 5-Pin SOT-23 T/R
TEXAS INSTRUMENTS LMV321M5/NOPB. OP AMP, 1MHZ, 1V/uS, SOT-23-5, FULL REEL
Single, 5.5-V, 1-MHz, RRO op amp 5-SOT-23 -40 to 125
Operational Amplifier, 1 Func, 7000uV Offset-Max, BICMOS, PDSO5
Operational Amplifier (Op-Amp) IC; No. of Amplifiers:1; Slew Rate:1V/µs; Supply Voltage Min:2.7V; Supply Voltage Max:5.5V; No. of Pins:5; Bandwidth:1MHz; Leaded Process Compatible:Yes; Offset Voltage:7mV; Package/Case:5-SOT-23 ;RoHS Compliant: Yes
