Texas Instruments LMV225UR/NOPB
артикул LMV225UR/NOPB
Texas Instruments
производитель
RF Detector 450MHz to 2000MHz 0dBm 4-Pin uSMD T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Frequency Band (MHz)
450 to 2000
Maximum Input Power (dBm)
0
Maximum Output Voltage (V)
2
Typical Output Current (mA)
5.3
Minimum Operating Supply Voltage (V)
2.7
Maximum Operating Supply Voltage (V)
5.5
Typical Supply Current (mA)
5.3
Minimum Input Power (dBm)
-30
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
85
Packaging
Tape and Reel
Standard Package Name
BGA
Supplier Package
uSMD
Pin Count
4
Mounting
Surface Mount
Package Height
0.22
Package Length
0.97
Package Width
0.97
PCB changed
4
Lead Shape
Ball
Показать все
Описание
RF Power Detector for CDMA and WCDMA in micro SMD 4-DSBGA
IC RF DETECT 450MHZ-2GHZ 4DSBGA
RF Detector 450MHz to 2000MHz 0dBm 4-Pin uSMD T/R
French Electronic Distributor since 1988
LMV225 RF POWER DETECTOR FOR CDM
RF Power Detector IC; Frequency Range I/P:450MHz to 2GHz; Power Range I/P:-30dBm to 0dBm; 3db Dynamic Range:30dB; Supply Current:4.8mA; Supply Voltage Min:2.7V; Supply Voltage Max:5.5V; Termination Type:SMD; Package/Case:4-uSMD ;RoHS Compliant: Yes
