Nexperia 74HCT240D,653
артикул 74HCT240D,653
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8542.39.00.01
Automotive
No
PPAP
No
Logic Family
HCT
Logic Function
Buffer/Line Driver
Number of Elements per Chip
2
Number of Channels per Chip
8
Number of Inputs per Chip
8
Number of Input Enables per Chip
0
Number of Outputs per Chip
8
Number of Output Enables per Chip
2 Low
Bus Hold
No
Polarity
Inverting
Maximum Propagation Delay Time @ Maximum CL (ns)
20@4.5V
Absolute Propagation Delay Time (ns)
45
Process Technology
CMOS
Input Signal Type
Single-Ended
Output Type
3-State
Maximum Low Level Output Current (mA)
6
Maximum High Level Output Current (mA)
-6
Minimum Operating Supply Voltage (V)
4.5
Typical Operating Supply Voltage (V)
5
Maximum Operating Supply Voltage (V)
5.5
Maximum Quiescent Current (uA)
8
Propagation Delay Test Condition (pF)
50
Maximum Power Dissipation (mW)
500
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Supplier Package
SO
Pin Count
20
Mounting
Surface Mount
Package Height
2.45(Max)
Package Length
13(Max)
Package Width
7.6(Max)
PCB changed
20
Показать все
Описание
74HCT Series 5.5V SMT Octal Buffer/Line Driver 3-State Inverting - SOIC-20
74HC240; 74HCT240 - Octal buffer/line driver; 3-state; inverting
Bus Driver, HCT Series, 2-Func, 4-Bit, Inverted Output, CMOS, PDSO20
IC INVERTER DUAL 4-INPUT 20SOIC
Buffer/Line Driver 8-CH Inverting 3-ST CMOS 20-Pin SO T/R
74HCT240D/SO20/DONTUSE REEL 13
