ГлавнаяКаталогStandard and Specialty LogicSpecialty LogicBuffers and Line DriversNexperia 74LVC244APW,118

Nexperia 74LVC244APW,118

артикул 74LVC244APW,118

Nexperia

производитель

Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP T/R

Datasheet PDF | 309 кб

По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.

Отправить запрос

Технические параметры

EU RoHS

Compliant

ECCN (US)

EAR99

Part Status

Active

HTS

8542.39.00.01

Automotive

PPAP

Logic Family

LVC

Logic Function

Buffer/Line Driver

Number of Elements per Chip

Number of Channels per Chip

Number of Inputs per Chip

Number of Input Enables per Chip

Number of Outputs per Chip

Number of Output Enables per Chip

2 Low

Bus Hold

Polarity

Non-Inverting

Maximum Propagation Delay Time @ Maximum CL (ns)

2.9(Typ)@3.3V; 3.4(Typ)@2.7V

Absolute Propagation Delay Time (ns)

Process Technology

CMOS

Input Signal Type

Single-Ended

Output Type

3-State

Maximum Low Level Output Current (mA)

Maximum High Level Output Current (mA)

-24

Minimum Operating Supply Voltage (V)

1.2

Typical Operating Supply Voltage (V)

3.3; 2.5; 1.8

Maximum Operating Supply Voltage (V)

3.6

Tolerant I/Os (V)

Typical Quiescent Current (uA)

0.1

Maximum Quiescent Current (uA)

Propagation Delay Test Condition (pF)

Maximum Power Dissipation (mW)

500

Minimum Operating Temperature (В°C)

-40

Maximum Operating Temperature (В°C)

125

Packaging

Tape and Reel

Standard Package Name

SOP

Pin Count

Supplier Package

TSSOP

Mounting

Surface Mount

Package Height

0.95(Max)

Package Length

6.6(Max)

Package Width

4.5(Max)

PCB changed

Lead Shape

Gull-wing

Показать все

Описание

74LVC 4 Buffers£¬Non-OppositeSide 2 TSSOP-20 Buffers / Drivers ROHS

74LVC Series 3.6 V SMT Octal Buffer/Line Driver - TSSOP-20

Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP T/R

74LVC244A; 74LVCH244A - Octal buffer/line driver; 3-state

Bus Driver, LVC/LCX/Z Series, 2-Func, 4-Bit, True Output, CMOS, PDSO20

74LVC244 Tape & Reel (TR) 2005 Nickel/Palladium/Gold (Ni/Pd/Au) logic receiver 24mA 24mA 20ns 1.1mm 500mW

Buffers & Line Drivers OCTAL BUFF/LDRVR 3ST 3.3V

IC BUF NON-INVERT 3.6V 20TSSOP

IC,74LVC244APW,118,3.3V OCTAL 3-STATE DRIVER

NOW NEXPERIA 74LVC244APW - BUS D

BUFFER/LINE DRIVER, OCTAL, TSSOP-20; Logic Device Type:Buffer / Line Driver, Non Inverting; Supply Voltage Min:1.65V; Supply Voltage Max:3.6V; Logic Case Style:TSSOP; No. of Pins:20; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2013)
