Nexperia PDTC144ET,215
артикул PDTC144ET,215
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8541.21.00.95
SVHC
Yes
Automotive
Yes
PPAP
Unknown
Type
NPN
Configuration
Single
Maximum Collector-Emitter Voltage (V)
50
Maximum Continuous DC Collector Current (mA)
100
Minimum DC Current Gain
80@5mA@5V
Typical Input Resistor (kOhm)
47
Typical Resistor Ratio
1
Maximum Collector-Emitter Saturation Voltage (V)
0.15@0.5mA@10mA
Maximum Power Dissipation (mW)
250
Minimum Operating Temperature (В°C)
-65
Maximum Operating Temperature (В°C)
150
Supplier Temperature Grade
Automotive
Packaging
Tape and Reel
Supplier Package
SOT-23
Pin Count
3
Standard Package Name
SOT
Mounting
Surface Mount
Package Height
1(Max)
Package Length
3(Max)
Package Width
1.4(Max)
PCB changed
3
Lead Shape
Gull-wing
Показать все
Описание
PDTC144ET - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ
Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, NPN, Silicon, TO-236AB
Trans Digital BJT NPN 50V 100mA 250mW Automotive 3-Pin SOT-23 T/R
NPN - Pre-Biased 250mW 100mA 50V SOT-23(SOT-23-3) Digital Transistors ROHS
TRANS, NPN, W/RES 2X47K, 50V, SOT23; Collector Emitter Voltage V(br)ceo:50V; Continuous Collector Current Ic:100mA; Base Input Resistor R1:47kohm; Base-Emitter Resistor R2:47kohm; Resistor Ratio, R1 / R2:1; RF Transistor Case:SOT-23; No. of Pins:3; SVHC:No SVHC (20-Jun-2013); MSL:-
