Bourns SRR6028-471Y
артикул SRR6028-471Y
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8504.50.80.00
Automotive
No
PPAP
No
Type
Power
Technology
Wirewound
Protection Style
Shielded
Core Material
Ferrite
Inductance (H)
470u
Tolerance
30%
Inductance Test Frequency (Hz)
100K
Maximum DC Current (A)
0.27
Maximum Saturation Current (A)
0.22
Maximum DC Resistance (Ohm)
2.1
Minimum Quality Factor
11
Quality Test Frequency (Hz)
796K
Minimum Self Resonant Frequency (Hz)
9M(Typ)
Number of Terminals
2
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Product Length (mm)
7
Mounting
Surface Mount
Product Depth (mm)
7
Product Height (mm)
3
Показать все
Описание
This power SRR6028-471Y surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has an operating temperature range of -40 В°C to 125 В°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 7 mm long, 3 mm tall and 7 mm deep. This SMD inductor has a maximum DC current of 270m A with a maximum resistance of 2.1 Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 9M(Typ) Hz. This device utilizes wirewound technology. It has an inductance of 470u H.
