Bourns SRN3015-4R7M
артикул SRN3015-4R7M
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8504.50.80.00
Automotive
No
PPAP
No
Type
Power
Technology
Wirewound
Protection Style
Semi-Shielded
Core Material
Ferrite
Inductance (H)
4.7u
Tolerance
20%
Inductance Test Frequency (Hz)
1M
Maximum DC Current (A)
1.4
Maximum Saturation Current (A)
1.2
Maximum DC Resistance (Ohm)
0.136
Minimum Quality Factor
14
Quality Test Frequency (Hz)
7.96M
Minimum Self Resonant Frequency (Hz)
65M(Typ)
Number of Terminals
2
Case Size
1212
Minimum Operating Temperature (В°C)
-40
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Product Length (mm)
3.1
Mounting
Surface Mount
Product Depth (mm)
3.1
Product Height (mm)
1.5
Показать все
Описание
This power SRN3015-4R7M surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has an operating temperature range of -40 В°C to 125 В°C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 65M Hz. This SMD inductor has a maximum DC current of 1.4 A with a maximum resistance of 136m Ohm. This product is 3.1 mm long, 1.5 mm tall and 3.1 mm deep. It has a tolerance of 20%. It has an inductance of 4.7u H. This device utilizes wirewound technology.
