Murata LQM2MPN2R2MG0L
артикул LQM2MPN2R2MG0L
Murata
производитель
Inductor Power Chip Shielded Multi-Layer 2.2uH 20% 1MHz Ferrite 1.2A 0.138Ohm DCR 0806 T/R
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8504.50.80.00
Automotive
No
PPAP
No
Type
Power Chip
Technology
Multi-Layer
Protection Style
Shielded
Core Material
Ferrite
Inductance (H)
2.2u
Tolerance
20%
Inductance Test Frequency (Hz)
1M
Maximum DC Current (A)
1.2
Maximum DC Resistance (Ohm)
0.138
Minimum Self Resonant Frequency (Hz)
40M
Number of Terminals
2
Case Size
0806
Minimum Operating Temperature (В°C)
-55
Maximum Operating Temperature (В°C)
125
Packaging
Tape and Reel
Product Length (mm)
2.15
Mounting
Surface Mount
Product Depth (mm)
1.75
Product Height (mm)
1
Показать все
Описание
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power chip LQM2MPN2R2MG0L surface mount inductor from Murata to save valuable space. This SMD inductor has an operating temperature range of -55 В°C to 125 В°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 20%. It has an inductance of 2.2u H. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 40M Hz. This device utilizes multi-layer technology. This SMD inductor has a maximum DC current of 1.2 A with a maximum resistance of 138m Ohm. This product is 2.15 mm long, 1 mm tall and 1.75 mm deep.
