Taiyo Yuden NR3015T2R2M
артикул NR3015T2R2M
Taiyo Yuden
производитель
Inductor Power Shielded Wirewound 2.2uH 20% 100KHz Ferrite 1.5A 0.072Ohm DCR 1212 T/R
Datasheet
PDF | 289 кб
Отсортировать цены
по количеству
по количеству
По данному товару предложений не найдено. Оставьте заявку, и мы вам перезвоним.
Технические параметры
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8504.50.80.00
Automotive
No
PPAP
No
Type
Power
Technology
Wirewound
Protection Style
Shielded
Core Material
Ferrite
Inductance (H)
2.2u
Tolerance
20%
Inductance Test Frequency (Hz)
100K
Maximum DC Current (A)
1.5
Maximum Saturation Current (A)
1.48
Maximum DC Resistance (Ohm)
0.072
Minimum Self Resonant Frequency (Hz)
64M
Number of Terminals
2
Case Size
1212
Minimum Operating Temperature (В°C)
-25
Maximum Operating Temperature (В°C)
120
Packaging
Tape and Reel
Product Length (mm)
3.1
Mounting
Surface Mount
Product Depth (mm)
3.1
Product Height (mm)
1.5
Показать все
Описание
Inductor Power Shielded Wirewound 2.2uH 20% 100KHz Ferrite 1.5A 0.072Ohm DCR 1212 T/R
General Purpose Inductor, 2.2uH, 20%, 1 Element, Ferrite-Core, SMD, 1212
NR Series 2.2 uH ±20% 1.5 A 72 mOhm SMT Wirewound Power Inductor
Power Inductor (SMD), 2.2 uH, ± 20%, 1.5 A, Shielded, 1.48 A, 3mm x 3mm x 1.5mm
Inductor, Shielded, 2.2Uh, 1.48A, Smd, Full Reel; Product Range:nr Series; Inductance:2.2 H; Rms Current (Irms):1.5A; Saturation Current (Isat):1.48A; Inductor Construction:shielded; Dc Resistance Max:0.06Ohm; Packaging:tape & Reel Rohs Compliant: Yes
